Description
Decade Resistance Box (Model No. DRB-8T)
– Portable, Stable Reading & most suitable for Meggar Testing.
– Resistance Range : 100KΩ To 11 tera Ω in 8 Decades X 100K, 1M,10M, 100 Megohms, 1G,10 G, 100G, 1 Tera-ohm
– Rated Max. Voltage : 1kV for 100KΩ, 1MΩ dials :5kV for 10MΩ dial : 10kV for 100MΩ and higher
– Accuracy: ±0.5% for 100KΩ, 1MΩ, 10MΩ Dial | ±1% for 100MΩ, 1 GΩ | ±2% for 10GΩ | ±5% for 100GΩ, 1 TΩ
– Dials of 100K, 1M & 10 Meg-ohms can also be used at 5000V when they are connected in series with high value dial.
– Have low current contact switches & low current two terminals binding post
